Press Releases

27 GHz Bandwidth DDR3 SDRAM Socket for PBGA543 Quickly and easily Socket your 23x32mm, 1mm pitch BGA543 packages on any PCB without significant performance loss

May 2019

Ironwood Electronics has recently introduced a new high performance BGA socket for 1mm pitch, 543 pin BGA IC's. The SG-BGA-6485 socket is designed for IC size - 23x32mm package size and operates at bandwidths up to 27 GHz with less

Lever Actuated Spring Pin Socket for BGA676 Socket your 676 pin BGA using Extreme Temperature Socket with Superior Electrical Performance

May 2019

Ironwood Electronics recently introduced a new BGA socket addressing high performance requirements - CBT-BGA-6087. The contactor is a stamped spring pin with 19 gram actuation force per ball and cycle life of 125,000 insertions. The self inductance of the contactor

30 GHz BGA Socket for BGA25 Socket your 25 pin BGA package 0.4mm pitch without significant performance loss and with minimal increase in PC Board footprint

April 2019

Ironwood Electronics has recently introduced a new high performance BGA socket for 0.4mm pitch BGA 25 pin device. The CG-BGA-5030 socket is designed for 2.125x2.225 mm package size and operates at bandwidth up to 30 GHz with less than 1dB

Clamshell Spring Pin Socket for SAW Filter Socket your LGA6 using Extreme Temperature Socket with Superior Electrical Performance

April 2019

Ironwood Electronics recently introduced a new LGA socket addressing high performance requirements for custom pitch devices – CBT-LGA-5017. The contactor is a stamped spring pin with 14.5 gram actuation force per pin and cycle life of 100,000 insertions. The self

27 GHz Bandwidth Epoxy mount Socket for 1mm Pitch Micron Embedded Parallel NOR Flash Users can socket their 1mm pitch, 64ball BGA devices without performance loss or little board space, no mounting holes, no solder

March 2019

Ironwood Electronics’ new high performance Socket – SG-BGA-6484 allow 1 mm pitch, 11x13mm body IC’s to be used in socket and operate without compromising performance in very high speed memory applications. The new 27 GHz bandwidth sockets easily support very
